1 x TRACOPOWER Isolated DC-DC Converter TEN 40-4833, Vin 36-75V dc - TRACOPOWER
roll over the image to zoom in
£0.00
£92.99
RS 781-3531
Unit Quantity:
1
Unit Type:
Unit
TRACOPOWER
TRACOPOWER Through Hole Isolated DC-DC Converter, Vin 36 → 75 V dc, I/O isolation 1500V dc
- BMUK Part # :-781-3531
- BrandTRACOPOWER
- Mfr. Part No.TEN 40-4833
-
- You will get 1 DC-DC Converter
Product Details
Traco 40W Single/Triple Output Regulated Isolated DC-DC Converter - TEN 40 Series
40W single/triple output regulated isolated DC-DC converters with a high power density. These single/triple output regulated isolated DC-DC converters have a high efficiency which allows an operating temperature range from -40°C to + 70°C. This series of single/triple output regulated isolated DC-DC converters are suitable for use in communication systems, industrial electronics, and distributed power systems.
Very high power density: 40W in a 51x51x10mm package
Wide 2:1 input range
Models with single, and triple output
Very high efficiency up to 89%
Remote on/off
Short circuit protection
Shielded metal case
| Connection Data | ||
| Pin | Single O/P | Triple O/P |
| 1 | +Vin (Vcc) | +Vin (Vcc) |
| 2 | -Vin (GND) | -Vin (GND) |
| 3 | Remote on/off | Remote on/off |
| 4 | No function | +Vout 2 |
| 5 | -Sense | Common |
| 6 | +Sense | -Vout 3 |
| 7 | +Vout | +Vout 1 |
| 8 | -Vout | -Vout 1 |
| 9 | Trim | No function |
Note
Single o/p derates above 45°C, Triple o/p derates above 40°C.
Traco - 40W to 60W
Specifications
| Output Voltage | ±12 V dc, 3.3 V dc | |
| Input Voltage Range | 36 → 75 V dc | |
| Input Voltage Nominal | 48 V dc | |
| Isolation Voltage | 1500V dc | |
| Output Current | 6 A, 400 mA | |
| Mounting Type | Through Hole | |
| Number of Outputs | 3 | |
| Efficiency | 86% | |
| Minimum Temperature | -40°C | |
| Maximum Temperature | +75°C | |
| Load Regulation | 2 %, 5 % | |
| Line Regulation | 1 %, 5 % | |
| Weight | 65g | |
| Length | 50.8mm | |
| Ripple And Noise | 50 mV Pk-Pk, 75 mV Pk-Pk | |
| Depth | 10.2mm | |
| Series | TEN 40 | |
| MTBF | 360000h |
