    Recom RP12 AW Through Hole, Vout ±15V dc Isolated DC-DC Converter, Vin 18 → 75 V dc, I/O isolation 1600V dc


    • BMUK Part # :-163-518
    • BrandRecom
    • Mfr. Part No.RP12-4815DAW
    •
    •
    • You will get 1 DC-DC Converter






    Product Details

    Recom 12W Single/Dual Output Regulated Isolated DC-DC Converter - RP12-AW Series

    High power density
    Ultra-wide 4:1 input voltage range
    Regulated outputs
    1.6kV input / output isolation
    Pi input filter, meets EN 55022 Class A/B with external filter
    Remote On/Off Control
    Under voltage, over voltage (single), over load and short circuit protection
    Shielded metal case with insulated baseplate
    24-pin DIP with industry standard pin-out

    Connection Data
    PinSingle OutputDual Output
    1Remote on/offRemote on/off
    2-Vin-Vin
    3-Vin-Vin
    9NCCommon
    11NC-V out
    14+V out+Vout
    16-V outCommon
    22+Vin+Vin
    23+Vin+Vin

    Note

    Operating temperature is without de-rating.





    Recom - 7.5W to 15W

    Specifications


    		Output Voltage±15V dc

    		Input Voltage Range18 → 75 V dc

    		Input Voltage Nominal48 V dc

    		Isolation Voltage1600V dc

    		Output Current±0.4A

    		Mounting TypeThrough Hole

    		Number of Outputs2

    		PackageDIP

    		Minimum Temperature-40°C

    		Maximum Temperature+65°C

    		Length31.8mm

    		Board Level ComponentsY

    		Depth10.2mm

    		SeriesRP12 AW







    For a Specification PDF Please CLICK HERE
