1 x Murata NXE1S0505MC 1W Isolated DC-DC Converter, 4.5-5.5V In 5V Out, 3KV Iso - Murata Power Solutions
roll over the image to zoom in
£0.00
£8.99
RS 885-4723
Unit Quantity:
1
Unit Type:
Unit
Location:
APR BOX S
Murata Power Solutions
Murata Power Solutions Surface Mount 1W Isolated DC-DC Converter, Vin 4.5 → 5.5 V dc, I/O isolation 3000V dc
- BMUK Part # :-885-4723
- BrandMurata Power Solutions
- Mfr. Part No.NXE1S0505MC
-
- You will get 1 DC-DC Converter
Product Details
Murata Isolated 1W Single Output DC/DC Converter - NXE1 Series
The Murata NXE1 is a series of low cost 1 Watt DC-DC converters. These ultra-compact surface mount DC-DC converters have a profile over 30% lower than the industry standard of 7mm and a transformer that is embedded in the substrate, making them perfect for use where space is critical. With an industry standard pin compatible footprint the NXE1 series is ideal for a replacement product in existing designs as well as for new compact applications. These isolated DC-DC converters can be used across the full industrial temperature range from -40 to +85 degrees C.
Halogen Free
Patents pending
Lower Profile
3kVDC Isolation “Hi Pot Test”
Substrate Embedded Transformer
Automated Manufacture
Industry Standard Footprint
Short Circuit Protection
Approvals
UL60950, UL60101 pending
Murata Power Solutions - SMD
Specifications
| Output Voltage | 5V | |
| Input Voltage Range | 4.5 → 5.5 V dc | |
| Input Voltage Nominal | 5 V dc | |
| Isolation Voltage | 3000V dc | |
| Power Rating | 1W | |
| Output Current | 200mA | |
| Mounting Type | Surface Mount | |
| Number of Outputs | 1 | |
| Package | SMA | |
| Efficiency | 66% | |
| Minimum Temperature | -40°C | |
| Maximum Temperature | +85°C | |
| Load Regulation | 10% | |
| Line Regulation | 1.2% | |
| Application | Automation, Industrial | |
| Ripple And Noise | 50mV Pk-Pk | |
| Width | 10.41mm | |
| Protection Features | Short Circuit Protection | |
| Depth | 4.5mm | |
| Maximum Input Current | 300mA | |
| Weight | 1g | |
| Length | 12.7mm | |
| Power Signal Conversion Type | DC-DC | |
| Series | NXE1 | |
| Standards Met | ANSI/AAMI ES60601-1 Standard, RoHS Compliant, UL 60950 |
