1 x Analog Devices AD594CDZ Temperature Sensor, Through Hole, -55-+125 °C 14-Pin - Analog Devices
roll over the image to zoom in
£0.00
£112.99
RS 709-5351
Unit Quantity:
1
Unit Type:
Unit
Analog Devices
Analog Devices AD594CDZ Temperature Sensor, -55 → +125 °C, 14-Pin TO-116
- BMUK Part # :-709-5351
- BrandAnalog Devices
- Mfr. Part No.AD594CDZ
-
- You will get 1 Temperature Sensor
Product Details
AD595...AD597 Thermocouple Amplifiers, Analog Devices
The AD594/595/596/597 series of type J/K thermocouple amplifiers are a combination of an instrumentation amplifier and thermocouple cold junction compensator roviding an output of 10mV/°C.
AD594 for type J thermocouples, optimised operating temperature range 0°C to 50°C
AD595 for type K thermocouples, optimised operating temperature range 0°C to 50°C
AD596 for type J thermocouples, optimised operating temperature range 25°C to 100°C
AD597 for type K thermocouples, optimised operating temperature range 25°C to 100°C
All versions have a measurement range equal to the full range of the relevant thermocouple type.
Thermocouple Amplifiers
Specifications
| Sensor Function | Temperature | |
| Output Type | Analogue | |
| Interface Type | Analogue | |
| Accuracy | ±1°C | |
| Mounting Type | Through Hole | |
| Pin Count | 14 | |
| Operating Temperature Range | -55 → +125 °C | |
| Minimum Operating Temperature | -55 °C | |
| Maximum Operating Temperature | +125 °C | |
| Minimum Operating Supply Voltage | 4.5 V | |
| Maximum Operating Supply Voltage | 5.5 V | |
| Package Type | TO-116 | |
| Length | 17.78mm | |
| Height | 2.41mm | |
| Width | 7.37mm | |
| Dimensions | 17.78 x 7.37 x 2.41mm | |
| Board Level Components | Y | |
| Sensor Gain | 10mV/°C |
