5 x STMicroelectronics STP60NF06L MOSFET 60A 60V N-Chan Logic Level Gate Arduino - STMicroelectronics

roll over the image to zoom in

£0.00
£17.99
RS 485-7816
Earn0
reward points

In stock: 903

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    5
    Unit Type:
    Unit
    Location:
    TS BRA-8M + ES Bulk Boxes


    STMicroelectronics



    N-Channel MOSFET, 60 A, 60 V, 3-Pin TO-220 STMicroelectronics STP60NF06L


    • BMUK Stock No.485-7816
    • BrandSTMicroelectronics
    • Mfr Part No.STP60NF06L
    •
    • You will get a pack of FIVE MOSFET's
    •
    • These devices have Logic Level Gates making them ideal for applications on Arduino and PIC Micro controllers for example, they also have a very low On Resistance of under 14 mΩ










    Specifications

    Maximum Operating Temperature
    +175 °C
    Maximum Continuous Drain Current
    60 A
    Package Type
    TO-220
    Maximum Power Dissipation
    110 W
    Mounting Type
    Through Hole
    Width
    4.6mm
    Height
    9.15mm
    Transistor Material
    Si
    Number of Elements per Chip
    1
    Length
    10.4mm
    Transistor Configuration
    Single
    Brand
    STMicroelectronics
    Series
    STripFET II
    Minimum Operating Temperature
    -65 °C
    Minimum Gate Threshold Voltage
    1V
    Maximum Drain Source Resistance
    14 mΩ
    Maximum Drain Source Voltage
    60 V
    Pin Count
    3
    Typical Gate Charge @ Vgs
    35 nC @ 4.5 V
    Channel Mode
    Enhancement
    Channel Type
    N
    Maximum Gate Source Voltage
    -15 V, +15 V
