5 x Infineon IRF9Z24NPBF P-channel MOSFET, 12A, 55V, 3-Pin - Infineon
roll over the image to zoom in
£0.00
£5.99
RS 919-4858
Unit Quantity:
5
Unit Type:
Unit
Location:
TS BRA-5i
Infineon
Infineon IRF9Z24NPBF P-channel MOSFET, 12 A, 55 V, 3-Pin TO-220AB
- BMUK Part # :-919-4858
- BrandInfineon
- Mfr. Part No.IRF9Z24NPBF
-
- You will get a pack of 5 Transistors
Product Details
P-Channel Power MOSFET 40V to 55V, Infineon
Infineon's range of discrete HEXFET® power MOSFETs includes P-channel devices in surface mount and leaded packages and form factors that can address almost any board layout and thermal design challenge. Across the range benchmark on resistance drives down conduction losses, allowing designers to deliver optimum system efficiency.
MOSFET Transistors, Infineon
Infineon offers a large and comprehensive portfolio of MOSFET devices which includes the CoolMOS, OptiMOS and StrongIRFET families. They deliver best-in-class performance to bring more efficiency, power density and cost effectiveness. Designs requiring high quality and enhanced protection features benefit from AEC-Q101 industry standards Automotive qualified MOSFETs.
Specifications
| Channel Type | P | |
| Maximum Continuous Drain Current | 12 A | |
| Maximum Drain Source Voltage | 55 V | |
| Maximum Drain Source Resistance | 175 mΩ | |
| Maximum Gate Threshold Voltage | 4V | |
| Minimum Gate Threshold Voltage | 2V | |
| Maximum Gate Source Voltage | ±20 V | |
| Package Type | TO-220AB | |
| Mounting Type | Through Hole | |
| Pin Count | 3 | |
| Transistor Configuration | Single | |
| Channel Mode | Enhancement | |
| Category | Power MOSFET | |
| Maximum Power Dissipation | 45 W | |
| Minimum Operating Temperature | -55 °C | |
| Typical Turn-On Delay Time | 13 ns | |
| Transistor Material | Si | |
| Maximum Operating Temperature | 175 °C | |
| Series | HEXFET | |
| Height | 8.77mm | |
| Typical Turn-Off Delay Time | 23 ns | |
| Number of Elements per Chip | 1 | |
| Typical Input Capacitance @ Vds | 350 pF @ 25 V | |
| Typical Gate Charge @ Vgs | 19 nC @ 10 V |
