1x STMicroelectronics STU9N60M2 N-Channel MOSFET, 5.5A 650V MDmesh M2 3-Pin IPAK - STMicroelectronics
roll over the image to zoom in
£0.00
£5.49
RS 168-6997
Unit Quantity:
1
Unit Type:
Unit
Model:
STU9N60M2
Location:
TS BRA-1N
STMicroelectronics
- BMUK Stock No.168-6997
- BrandSTMicroelectronics
- Mfr Part No.STU9N60M2
- You will get ONE mosfet
Product Details
N-channel MDmesh™ M2 Series, STMicroelectronics
A range of high-voltage power MOSFETs from STMicroelecronics. With their low gate charge and excellent output capacitance characteristics, the MDmesh M2 series are perfect for use in resonant-type switching supplies (LLC converters).
MOSFET Transistors, STMicroelectronics
Specifications
Maximum Operating Temperature
+150 °C
Maximum Continuous Drain Current
5.5 A
Package Type
IPAK (TO-251)
Maximum Power Dissipation
60 W
Mounting Type
Through Hole
Width
2.4mm
Height
6.2mm
Dimensions
6.6 x 2.4 x 6.2mm
Transistor Material
Si
Number of Elements per Chip
1
Length
6.6mm
Transistor Configuration
Single
Typical Turn-On Delay Time
8.8 ns
Brand
STMicroelectronics
Typical Turn-Off Delay Time
22 ns
Series
MDmesh M2
Minimum Operating Temperature
-55 °C
Maximum Gate Threshold Voltage
4V
Minimum Gate Threshold Voltage
2V
Maximum Drain Source Resistance
780 mΩ
Maximum Drain Source Voltage
650 V
Pin Count
3
Category
Power MOSFET
Typical Gate Charge @ Vgs
10 nC @ 10 V
Channel Mode
Enhancement
Typical Input Capacitance @ Vds
320 pF@ 10 V
Channel Type
N
Maximum Gate Source Voltage
-25 V, +25 V
