2000 x Vishay Thin Film Precision Surface Mount Resistor 2309 Case 5.62kΩ ±1% - Vishay

roll over the image to zoom in

£0.00
£82.99
RS 678-8107
Earn0
reward points

In stock: 1

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    2000
    Unit Type:
    Unit
    Location:
    APR BOX J


    Vishay


    Vishay MMB0207 Series Thin Film Precision Thin Film Surface Mount Resistor 2309 Case 5.62kΩ ±1% 0.4W ±50ppm/°C


    • BrandVishay
    • Mfr. Part No.MMB02070C5621FB700
    •  Vishay
    •
    • You will get 2000 Resistors on 1 Reel
    •




    Vishay MMB0207 Series Thin Film Precision Thin Film Surface Mount Resistor 2309 Case 5.62kΩ ±1% 0.4W ±50ppm/°C

    Image representative of range



    Product Details

    MMB 0207 - Professional

    Advanced thin film technology
    Excellent overall stability: exceeds Class 0.25
    Force-fitted steel caps, tin plated on nickel barrier
    Pure Sn termination on Ni barrier layer
    Compatible with lead (Pb)-free and lead-containing soldering processes

    Case Type0207
    TechnologyThin Film
    Resistance Tolerance1%
    Power Rating0.4W
    Temperature Coefficient50 ppm/°C
    Operating Temperature-55 → 125 °C

    Approvals

    EN 140401-803

    Approvals

    EN 140401-803

    Metal Electrode Leadless Face SMT Resistors

    Specifications


    		Resistance5.62 kΩ

    		Package/Case2309

    		Tolerance±1%

    		Power Rating0.4W

    		Temperature Coefficient±50ppm/°C

    		TechnologyThin Film

    		Dimensions2.2 (Dia.) x 5.8mm

    		Length5.8mm

    		SeriesMMB0207

    		Minimum Operating Temperature-55°C

    		Maximum Operating Temperature+125°C

    		Case StyleMoulded

    		Maximum Temperature Coefficient+50ppm/°C

    		Minimum Temperature Coefficient-50ppm/°C
