1x HS50 2R2 J Arcol Wire Wound Chassis Mount Resistor, 2.2 Ohm 50W ±5% - Arcol

roll over the image to zoom in

£0.00
£6.95
RS 158-317 / TSB-40D-RB2
Earn0
reward points

In stock: 3

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    TSB-40D-RB2


    Arcol

     HS50 2R2 J Arcol Wire Wound Chassis Mount Resistor, 2.2 Ohm 50W ±5%

    You will get ONE resistor

    Description:
    From Arcol, the HS50 series of aluminium housed resistors are high power and offer a balance of pulse power capability and volume. These panel mount resistors are manufactured in line with IEC 115 and MIL 18546. These panel mount resistors are designed for direct heatsink mounting with thermal compound, which ensures maximum performance.

    Features & Benefits:
    At high ambient temperature dissipation derates linearly to zero at +200 °C
    Wirewound to maximise high pulse capability
    Compact size for power rating

    Note:
    To achieve the given maximum performance rating of this power resistor, it is designed to be directly mounted on an appropriately matched heatsink and mounted using a thermal compound.

    Specifications:

    The HS50 2R2 J Arcol Wire Wound Chassis Mount Resistor is a high-power, precision resistor designed for reliable performance in demanding applications. With a resistance of 2.2 ohms and a power rating of 50W, this resistor is ideal for use in power electronics, automotive, and industrial equipment. Its wire-wound construction ensures accurate resistance values and durability under high load conditions.

    Features:

    • High Power Rating: Capable of handling up to 50W, making it suitable for high-power applications.
    • Precision Resistance: Offers a resistance value of 2.2 ohms with a tolerance of ±5%, ensuring accuracy in critical circuits.
    • Wire Wound Construction: Provides stability and reliability under high temperature and power conditions.
    • Chassis Mount Design: Facilitates easy installation and integration into various electronic and electrical systems.
    • Durable Performance: Built to withstand harsh environments and continuous operation.

    Specifications:

    • Type: Wire Wound Chassis Mount Resistor
    • Brand: Arcol
    • Model: HS50 2R2 J
    • Resistance: 2.2 Ohms
    • Power Rating: 50W
    • Tolerance: ±5%
    • Mounting Type: Chassis Mount
    • Construction: Wire Wound
