1 x BI Technologies Radial Thick Film Resistor 33kΩ ±5% 10W ±100ppm/°C - BI Technologies
roll over the image to zoom in
£0.00
£7.49
RS 625-3575
Unit Quantity:
1
Unit Type:
Unit
Resistance Rating:
33 kΩ
Power Rating:
10 W
BI Technologies
BI Technologies BPC5 Series Radial Thick Film Resistor 33kΩ ±5% 10W ±100ppm/°C
- BMUK Part # :-625-3575
- BrandBI Technologies
- Mfr. Part No.BPC10-333J LF
- You will get ONE Resistor
Image representative of range
Product Details
BPC Series non-inductive planar resistors 5 W 10 W
BPC series 5W to 10W Non-inductive vertical mounting planar resistors with excellent heat dissipation. The BPC series is ideal for high frequency applications including: limiting inrush current; power supplies; circuit snubber
| Max. voltage: | 300 Vac / 500 Vdc |
| Peak current: | 20 x rated current for up to 8 ms |
| Isolation voltage: | 5 KVDC |
Standards
UL 94 V-0
Non-Inductive - Through Hole Package
Specifications
| Resistance | 33 kΩ | |
| Power Rating | 10W | |
| Tolerance | ±5% | |
| Technology | Thick Film | |
| Series | BPC5 | |
| Case Style | Moulded | |
| Temperature Coefficient | ±100ppm/°C | |
| Termination Style | Radial | |
| Dimensions | 25.4 x 2.54 x 29.59mm | |
| Length | 25.4mm | |
| Depth | 2.54mm | |
| Height | 29.59mm | |
| Minimum Operating Temperature | -55°C | |
| Minimum Temperature Coefficient | -100ppm/°C | |
| Lead Pitch | 20.32mm | |
| Maximum Temperature Coefficient | +100ppm/°C | |
| Maximum Operating Temperature | +155°C |
For a Specification PDF Please CLICK HERE
TE Connectivity Black Heat Shrink Tubing, 9.5mm, 2:1, 10m Length
Product Details
DR-25 Heat shrink Tubing (Shrink Ratio 2:1)
Robust and flexible heat shrink tubing. It protects wires and cables against damage from chemicals, abrasion, and fluids. The tubing is ideal for use in high temperature environments as it has been specially designed for long term heat resistance and is flame retardant.
Features and Benefits
• Offers excellent protection and insulation
• Provides strain relief
• Performs well under long-term heat exposure
• The tubing is printed with the product description and size
• Shrink ratio of 2:1
• Use with System 25 range products for a complete cable harness system
Standards
VG95343 Part 5 Type D, VDE 0341/Pt 9005, AMS-DTL-23053/16, BS36-198 Part 3 10A.
High Temperature
Add product to Compare
Specifications
Not what you’re looking for? Select the attributes you require, then click the button below
| Sleeve Diameter | 9.5mm | |
| Shrunk Diameter | 4.8mm | |
| Colour | Black | |
| Sleeve Type | Heat Shrink | |
| Shrink Ratio | 2:1 | |
| Sleeve Length | 10m | |
| Material | Elastomer | |
| Minimum Operating Temperature | -75°C | |
| Maximum Operating Temperature | +150°C | |
| Dielectric Strength | 8kV/mm |
Microchip MCP7940M-I/SN Real Time Clock — Calendar, NV SRAM, 64B RAM 8-Pin SOIC
Product Details
MCP7940M I²C Real-Time Clock/Calendars
The Microchip MCP7940M is Real-Time Clock Calendar (RTCC) that supports I²C communications. The MCP7940M includes a digital trimming circuit for accuracy which can compensate for crystal tolerance and temperature.
The MCP7940M features a multi-functional output that can be configured as an alarm output, to output a selectable frequency square wave or as a general purpose output.
Features
2-Wire Serial Interface, I²C™ Compatible: I²C clock rate up to 400 kHzOn-Chip Digital Trimming/Calibration: ±1 ppm resolution, ±129 ppm range
Tracks Hours, Minutes, Seconds, Day of Week, Day, Month and Year
Leap Year Compensated to 2399
12/24 Hour Modes
Oscillator for 32.768 kHz Crystals: Optimised for 6-9 pF crystals
Dual Programmable Alarms
Versatile Output Pin
Wide Operating Voltage Range: 1.8V to 5.5V
Low Typical Timekeeping Current: 1.2μA at 3.3V
Real Time Clock Peripherals - Microchip
Add product to Compare
Specifications
Not what you’re looking for? Select the attributes you require, then click the button below
| Functions | Calendar, NV SRAM | |
| Date Format | DW:DM:M:Y | |
| Time Format | HH:MM:SS | |
| User RAM | 64B | |
| Bus Type | Serial-I2C | |
| Mounting Type | Surface Mount | |
| Package Type | SOIC | |
| Pin Count | 8 | |
| Dimensions | 4.9 x 3.9 x 1.25mm | |
| Length | 4.9mm | |
| Width | 3.9mm | |
| Height | 1.25mm | |
| Maximum Operating Supply Voltage | 5.5 V | |
| Minimum Operating Supply Voltage | 1.8 V | |
| Maximum Operating Temperature | +85 °C | |
| Minimum Operating Temperature | -40 °C |
