170 x Panasonic ZNR Series Metal Oxide Varistor 270pF 25A, 710V Varistor 430V - Panasonic
roll over the image to zoom in
£0.00
£46.99
RS 720-9904P
Unit Quantity:
170
Unit Type:
Unit
Location:
TS 50M
Panasonic
Panasonic ZNR Series Metal Oxide Varistor 270pF 25A, Clamping 710V, Varistor 430V
- BMUK Part # :-720-9904P
- BrandPanasonic
- Mfr. Part No.ERZV10D431
- You will get a pack of 170 Varistors
Image representative of range
Product Details
Metal Oxide Varistors ZNR Series, 10mm Diameter, Panasonic
Large surge current handling capacity in relation to the compact size
Increased 2-surge current handling capability in relation to standard varistors
| Type | Diameter (Nom. / Max.) (mm) | Pitch (mm) | Height (on PCB) (mm) |
| ERZV05 | 5 / 7 | 5 ±1 | 10 |
| ERZV07 | 7 / 8.5 | 5 ±1 | 11.5 |
| ERZV10 | 10 / 12.5 | 7.5 ±1 | 15.5 |
| ERZV14 | 14 / 16 | 7.5 ±1 | 19 |
| ERZV20 | 20 / 21.5 | 10 ±1 | 24.5 |
Specifications
| Varistor Voltage | 430V | |
| Maximum AC Voltage Rating | 275V | |
| Maximum DC Voltage Rating | 350V | |
| Clamping Voltage | 710V | |
| Clamping Current | 25A | |
| Energy | 80J | |
| Series | ZNR | |
| Diameter | 11.5mm | |
| Maximum Surge Current | 3500A | |
| Capacitance | 270pF | |
| Thickness | 6mm | |
| Dimensions | 11.5 (Dia.) x 6mm | |
| Lead Pitch | 7.5mm |
For a Specification PDF Please CLICK HERE
