10 x Murata 22pF Ceramic Multilayer Capacitor RPE5C2A220J2S1Z03A, 100V dc ±5% - Murata

roll over the image to zoom in

£0.00
£7.99
RS 652-9866
Earn0
reward points

In stock: 92

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    10
    Unit Type:
    Unit
    Location:
    MAIN SHELVES RIGHT HAND SIDE TOP SHELF


    Murata

    Murata 22pF Ceramic Multilayer Capacitor 100 V dc ±5% C0G Dielectric Through Hole Max. Op. Temp. +125°C


    • BMUK Part # :-652-9866
    • BrandMurata
    • Mfr. Part No.RPE5C2A220J2S1Z03A
    •  Murata
    •
    • You will get a pack of 10 Capacitors



    Murata 22pF Ceramic Multilayer Capacitor 100 V dc ±5% C0G Dielectric Through Hole Max. Op. Temp. +125°C

    Image representative of range



    Product Details

    RPE 131 / 132 Series

    C0G dielectric
    Epoxy Resin Dipped


    C0G (NP0) Dielectric

    Capacitors with stable and predictable characteristics over temperature and time, suitable for filtering, sample and hold and timing circuits where high Q and good stability are required.


    Specifications


    		Capacitance22 pF

    		Voltage100 V dc

    		Mounting TypeThrough Hole

    		DielectricC0G

    		Tolerance±5%

    		Dimensions5 x 2.5 x 3.5mm

    		Length5mm

    		Depth2.5mm

    		Height3.5mm

    		SeriesRPE

    		Tolerance Minus-5%

    		Tolerance Plus+5%

    		Minimum Operating Temperature-55°C

    		Maximum Operating Temperature+125°C

    		Temperature Coefficient±30ppm/°C

    		Terminal TypeThrough Hole
