1 x Cornell Aluminium Electrolytic Capacitor MLS112M075EK0A, 1100uF 75V dc - Cornell-Dubilier
roll over the image to zoom in
£0.00
£144.99
RS 744-1376
Unit Quantity:
1
Unit Type:
Unit
Location:
TS LB 2A
Cornell-Dubilier
Cornell-Dubilier Aluminium Electrolytic Capacitor 1100μF 75 V dc Through Hole EK MLS Series Lifetime 10000h +125°C
- BMUK Part # :-744-1376
- BrandCornell-Dubilier
- Mfr. Part No.MLS112M075EK0A
-
- You will get 1 Capacitor
Product Details
MLS series Flat Pack
A high-energy storage and box-shape make this series perfect for voltage holdup or filtering in military SEM-E modules, telecom circuit packs and computer cards. The MLS delivers up to 20 joules of energy storage in a 1/2” height with 50 year’s life at +45 ºC
Low-profile replacement for snap-in capacitors
Double the ripple capability when mounted on a heatsink
Nearly hermetic welded seal assures 50-year life
Will withstands more than 80,000 feet altitude
Stainless steel case
Specifications
| Capacitance | 1100 µF | |
| Technology | Electrolytic | |
| Voltage | 75 V dc | |
| Mounting Type | Through Hole | |
| Dimensions | 38.1 x 38.1 x 12.7mm | |
| Length | 38.1mm | |
| Depth | 44.45mm | |
| Height | 12.7mm | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | +125°C | |
| Lead Pitch | 254mm | |
| Construction | Radial | |
| Series | MLS | |
| Tolerance Plus | +20% | |
| Lead Diameter | 1.016mm | |
| Leakage Current | <=0.002 CV μA @ 5 min | |
| Ripple Current | 11.5A | |
| Lifetime | 10000h | |
| Equivalent Series Resistance | 112mΩ | |
| Terminal Type | Through Hole | |
| Package/Case | EK | |
| Tolerance Minus | -20% | |
| Tolerance | ±20% |
