1 x RS Pro Chassis Mount 15W Isolated DC-DC Converter, Vin 18-36V dc - RS Pro
roll over the image to zoom in
£0.00
£50.99
RS 183-792
Unit Quantity:
1
Unit Type:
Unit
Location:
ES 2F ALSO ???TS LEFT SHELF
RS Pro
RS Pro Chassis Mount 15W Isolated DC-DC Converter, Vin 18 → 36 V dc, I/O isolation 2kV ac, Vout 5V dc
- BrandRS Pro
- Mfr. Part No.SD-15B-5
-
- You will get 1 DC-DC Converter
Product Details
RS 15W Single Output Enclosed Regulated Isolated DC-DC Converter
High reliability
Wide 2:1 input voltage range
Regulated outputs
Easy installation - screw terminals
Adjustable output voltages for the three types are; 24 V dc is 21- 26.4 V dc; 12 V dc is 10.8 - 13.2 V dc and 5 V dc is 4.75 - 5.5 V dc
EMC meets EN 55022 Class B
LED power-on indicator
Short circuit, overload and overvoltage protection
2kV input / output isolation
Note
De-rating below 0 and above 40°C.
Specifications
| Output Voltage | 5V dc | |
| Input Voltage Range | 18 → 36 V dc | |
| Input Voltage Nominal | 24 V dc | |
| Isolation Voltage | 2kV ac | |
| Power Rating | 15W | |
| Output Current | 3A | |
| Mounting Type | Chassis Mount | |
| Number of Outputs | 1 | |
| Efficiency | 76% | |
| Minimum Temperature | -10°C | |
| Maximum Temperature | +60°C | |
| Load Regulation | ±0.5% | |
| Line Regulation | ±0.5% | |
| Current Limiting Method | Hiccup Current Limiting | |
| Output Voltage Adjustment Range | 4.75 → 5.5V | |
| Power Signal Conversion Type | DC-DC | |
| Length | 78mm | |
| Weight | 180g | |
| Special Features | 2 Year Warranty | |
| Protection Features | Over Voltage Protection, Overload Protection | |
| Width | 51mm | |
| Ripple And Noise | 100mV | |
| Standards Met | EN 55022 (CISPR22) Class B, EN 61000-4-2, ENV 50204, Heavy Industry Level Criteria A, 3, 4, 5, 6, 8 | |
| Regulator Type | Switch Mode | |
| Depth | 28mm |
