1 x Recom Isolated DC-DC Converter RP15-4812DF, Vin 36-75V dc, Vout ±12V dc - Recom

roll over the image to zoom in

£0.00
£54.99
RS 672-8271
Earn0
reward points

In stock: 4

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    TS 26F


    Recom





    Recom Isolated DC-DC Converter, Vin 36 → 75 V dc, Vout ±12V dc, I/O isolation 1600V dc


    • BMUK Part # :-672-8271
    • BrandRecom
    • Mfr. Part No.RP15-4812DF
    •  Recom
    •
    • You will get 1 DC-DC Converter

    Recom Isolated DC-DC Converter, Vin 36 → 75 V dc, Vout ±12V dc, I/O isolation 1600V dc








    Product Details

    Recom 15W Single/Dual Output Regulated Isolated DC-DC Converter - RP15-F Series

    2:1 wide input voltage range
    Regulated outputs
    1.6kVdc isolation
    Pi input filter
    Fixed operating frequency
    Six-sided continuous shield
    Over-voltage, under-voltage, over-load and short circuit protection
    Standard 2"x1" package
    Efficiency up to 86%

    Note

    MTBF to BELLCORE TR-NWT-000332.
    Operating temperature range is with derating.

    Approvals

    UL recognised

    Standards

    UL-60950-1



    https://uk.rs-online.com/largeimages/L6728230-01.gif



    Recom - 7.5W to 15W

    Specifications

    Output Voltage±12V dc
    Input Voltage Range36 → 75 V dc
    Input Voltage Nominal48 V dc
    Isolation Voltage1600V dc
    Output Current±0.625A
    Mounting TypeThrough Hole
    Number of Outputs2
    Minimum Temperature-40°C
    Maximum Temperature+85°C
    Length50.8mm
    Depth10.2mm




    For a Specification PDF Please  CLICK HERE
