1 x Linear Technology LTC1728ES5-1.8#TRMPBF, Triple Voltage Reference, 1.8-3V - Linear Technology
roll over the image to zoom in
£0.00
£5.49
RS 761-9181
Unit Quantity:
1
Unit Type:
Unit
Location:
TS 17B
Linear Technology
Linear Technology LTC1728ES5-1.8#TRMPBF, Triple Voltage Reference, 1.8 → 3 V, Reset Input, 5-Pin SOT-23
- BMUK Part # :-761-9181
- BrandLinear Technology
- Mfr. Part No.LTC1728ES5-1.8#TRMPBF
- You will get 1 IC
 |
Product Details
Microprocessor Supervisory & Reset Circuits, Linear Technology
Power supply voltage monitoring and supervisory circuits for use in desktop, laptop and notebook computers, test and measurement instruments, portable battery-powered equipment and multiple-output power supplies.
The Linear Technology series also offers front end protection with their Overcurrent/Overvoltage Protection, Circuit Breaker ICs and High Voltage Surge Stoppers. Supply monitors offer a guaranteed RESET signal down to a low supply voltage as well as accuracy, tolerances and adjustable thresholds.
Many applications for the Microprocessor Supervisory & Reset Circuits include DC/DC converter functionality, digital power management, systems monitor and control, automotive, avionic (DO-160 and MIL-STD1275 standards) and Industrial applications.
Supply Voltage Detector
Supply Voltage Monitor/Supervisor
Power Supply Supervisor
Microprocessor Supervisory
Microprocessor Voltage Supervisor
Microcontroller Reset Circuit
Controllers/Monitors
PMBus Digital Power Supply Managers
Microprocessor Supply Voltage Supervisory & Reset Circuits
Power supply voltage monitoring and supervisory circuits for use in desktop, laptop and notebook computers, test and measurement instruments, portable battery-powered equipment and multiple-output power supplies.
Supply Voltage Detector
Supply Voltage Supervisor
Power Supply Supervisor
Microprocessor Supervisory
Microprocessor Voltage Supervisor
Microcontroller Reset Circuit
Specifications
| Voltage Supervisor Type | Micropower Triple Supply Monitor | |
| Number of Supervisors | 3 | |
| Manual Reset | Yes | |
| Maximum Reset Threshold Voltage | 1.015V | |
| Minimum Reset Threshold Voltage | 0.985V | |
| Mounting Type | Surface Mount | |
| Package Type | SOT-23 | |
| Pin Count | 5 | |
| Dimensions | 3.1 x 1.75 x 1.3mm | |
| Height | 1.3mm | |
| Length | 3.1mm | |
| Maximum Monitored Voltage | 3V | |
| Maximum Operating Supply Voltage | 7 V | |
| Maximum Operating Temperature | +85 °C | |
| Width | 1.75mm | |
| Minimum Operating Supply Voltage | 1 V | |
| Minimum Operating Temperature | -40 °C | |
| Minimum Monitored Voltage | 1.8V |
