1 x Analog Devices REF01CPZ Fixed Series Voltage Reference 10V ±1.0 % 8-Pin PDIP - Analog Devices

roll over the image to zoom in

£0.00
£5.99
RS 111-1103
Earn0
reward points

In stock: 50

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    TS BRA-3K


    Analog Devices

    Analog Devices REF01CPZ, Fixed Series Voltage Reference 10V, ±1.0 % 8-Pin, PDIP


    • BMUK Stock No.111-1103
    • BrandAnalog Devices
    • Mfr Part No.REF01CPZ
    •
    •  Analog Devices
    •
    • You will get ONE voltage reference IC




    Analog Devices REF01CPZ, Fixed Series Voltage Reference 10V, ±1.0 % 8-Pin, PDIP



    Product Details

    Voltage Reference, 10V, Analog Devices








    Voltage References, Analog Devices

    Specifications

    Maximum Operating Temperature
    +85 °C
    Initial Accuracy
    ±1.0 %
    Topology
    Series
    Line Regulation
    150 ppm/V
    Length
    9.27mm
    Brand
    Analog Devices
    Package Type
    PDIP
    Load Regulation
    150 ppm/mA
    Mounting Type
    Through Hole
    Minimum Operating Temperature
    -40 °C
    Width
    7.24mm
    Nominal Voltage
    10V
    Height
    3.43mm
    Pin Count
    8
    Dimensions
    9.27 x 7.24 x 3.43mm
    Maximum Input Voltage
    36 V
    Maximum Output Current
    8mA
    Reference Type
    Fixed
    Maximum Output Voltage
    10.1 V
    Minimum Output Voltage
    9.9 V
