Analog Devices
Analog Devices AD581JH, Fixed Series Voltage Reference 10V, ±0.3 % 40 V max., 3-Pin TO-5
- BMUK Part # :-411-589
- BrandAnalog Devices
- Mfr. Part No.AD581JH
-
- You will get 1 Voltage Reference
Product Details
Voltage Reference, 10V, Analog Devices
Voltage References, Analog Devices
Precision Fixed and Adjustable Voltage Reference ICs utilizing series, shunt, or series/shunt topologies and available in both through-hole and surface mount packages. Voltage References are available with initial accuracies of ±0.02 to ±2%.
Specifications
| Nominal Voltage | 10V | |
| Package Type | TO-5 | |
| Reference Type | Fixed | |
| Initial Accuracy | ±0.3 % | |
| Mounting Type | Through Hole | |
| Topology | Series | |
| Maximum Output Current | 10mA | |
| Maximum Input Voltage | 40 V | |
| Pin Count | 3 | |
| Line Regulation | 0.005 %/V | |
| Load Regulation | 500 μV/mA | |
| Dimensions | 9.4 x 9.4 x 4.7mm | |
| Height | 4.7mm | |
| Maximum Operating Temperature | +70 °C | |
| Length | 9.4mm | |
| Width | 9.4mm | |
| Minimum Operating Temperature | 0 °C |
