Texas Instruments UCC27223PWP Dual MOSFET Power Driver 3.3A, 8.5-20V - Texas Instruments
roll over the image to zoom in
£0.00
£6.99
RS 661-3163
Unit Quantity:
1
Unit Type:
Unit
Location:
TS 50O
Texas Instruments
Texas Instruments UCC27223PWP Dual MOSFET Power Driver 3.3A, 8.5 → 20 V, HTSSOP 14-Pin
- BMUK Part # :-661-3163
- BrandTexas Instruments
- Mfr. Part No.UCC27223PWP
- You will get 1 IC
Product Details
MOSFET & IGBT Half-Bridge Gate Drivers, Texas Instruments
MOSFET & IGBT Drivers, Texas Instruments
Specifications
| Number of Drivers | 2 | |
| Minimum Operating Supply Voltage | 8.5 V | |
| Maximum Operating Supply Voltage | 20 V | |
| Driver Configuration | Inverting, Non-Inverting | |
| Mounting Type | Surface Mount | |
| Peak Output Current | 3.3A | |
| Number of Outputs | 2 | |
| Driver Type | High and Low Side | |
| Package Type | HTSSOP | |
| Pin Count | 14 | |
| Input Logic Compatibility | TTL | |
| High and Low Sides Dependency | Synchronous | |
| Height | 1.15mm | |
| Maximum Operating Temperature | +105 °C | |
| Dimensions | 5 x 4.4 x 1.15mm | |
| Length | 5mm | |
| Width | 4.4mm | |
| Minimum Operating Temperature | -40 °C |
