TDK-Lambda 30W, 1 Output, Embedded Switch Mode Power Supply (SMPS), 5V, 6A - TDK-Lambda
roll over the image to zoom in
£0.00
£48.99
RS 243-2409
Power Rating:
30W
Location:
TS LEFT SHELF
TDK-Lambda
TDK-Lambda 30W, 1 Output, Embedded Switch Mode Power Supply (SMPS), 5V, 6A
- BMUK Part # :-243-2409
- BrandTDK-Lambda
- Mfr. Part No.ZWS 30-5
Product Details
5 to 150W, Universal Input, Single Output, ZWS Series
Open PCB format units with optional cover kit. All units from 100W and above incorporate a passive filter for harmonic correction.
Conducted EMI conforms to EN55022-B
Power factor correction (100W and above)
Overvoltage and overcurrent protection
Fully regulated outputs
Operating temperature range -10°C to +60°C
Optional cover kits available (except for ZWS 5 and 10 types), see guide for suitable covers
| Cover Kit Guide | |
| Suitable Cover Kit | Stk No. |
| Cover kit for ZWS15 series | 243-2421 |
| Cover kit for ZWS30 series | 243-2364 |
| Cover kit for ZWS50 series | 243-2308 |
| Cover kit for ZWS100A series | 655-8555 |
| Cover kit for ZWS150A series | 655-8561 |
Note
Connectors are not provided, refer to manufacturers datasheet for suitable Molex or JST connectors.
Power ratings will be reduced when used with a cover kit.
Standards
EN60950; UL1950; CSA234; DENTORI; EN55022-B
Switch Mode - TDK-Lambda
Specifications
| Output Voltage | 5V | |
| Output Current | 6A | |
| Power Rating | 30W | |
| Input Voltage | 85 → 265 V ac, 110 → 330 V dc | |
| Number of Outputs | 1 | |
| Package Type | Open Frame | |
| Length | 133mm | |
| Width | 55.1mm | |
| Depth | 25.9mm | |
| Ripple And Noise | 120mV | |
| Load Regulation | 40mV | |
| Line Regulation | 20mV | |
| Minimum Temperature | -10°C | |
| Maximum Temperature | +60°C | |
| Efficiency | 75% | |
| Weight | 270g |
To view the datasheet please click here
