5 x PIC12F617-I/P 8 bit PIC Microcontroller 20MHz 2048 x 14 W Flash 128 B RAM - Microchip

roll over the image to zoom in

£0.00
£15.99
RS 703-7848 x 5
Earn0
reward points

In stock: 49

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1


    Microchip


     PIC12F617-I/P, 8 bit PIC Microcontroller 20MHz 2048 x 14 words Flash, 128 B RAM, 8-Pin PDIP

    Microchip

    You are looking at 5 of PIC12F617-I/P Microcontrollers in an 8 Pin PDIP Package,

    Product Details

    PIC12F6xx, PIC12F7xx and PIC12HVxxx 8-Bit PIC® Microcontrollers

    PIC12F6xx, PIC12F7xx and PIC12HVxxx families feature Microchip’s popular Mid Range core which adds interrupt capability, a deeper hardware stack and 35 14-bit instructions. Program memory is up to 3.5KB with data memory up to 128 Bytes. Extra features such as UART, 10-bit ADC, DAC, and Comparators can be found on selected devices. PIC12HVxxx devices feature an in-built shunt regulator offering 2-15V operation. Various ICD Interface Headers support development/debugging.


    PIC12F Microcontrollers

    Microchip PIC12F 8-bit PIC® Microcontrollers

    Microchip’s PIC12F Microcontrollers (MCUs) were the world’s first 8-Pin microcontrollers. Originally launched as One Time Programmable (OTP) parts, this range of devices continues to expand as Microchip adds extra features, further improves specifications and continues to offer ever greater value. Key to the success of the PIC12F was the internal RC oscillator that allowed six I/O channels in an 8-pin package. Later versions of this RC oscillator are configurable between 31kHz and 32MHz.


    Specifications
    To find a similar product, based on selected attributes, click the green button
    ADC Channels4ADC Resolution10bitADCs4 x 10 bitData Bus Width8bitDevice CorePICDimensions0.4 x 0.28 x 0.195inFamily NamePIC12Height0.195inInstruction Set ArchitectureRISCLength0.4inMaximum Frequency20MHzMaximum Number of CAN Channels0Maximum Number of Ethernet Channels    0Maximum Number of I2C Channels0Maximum Number of LIN Channels0Maximum Number of PCI Channels0Maximum Number of SPI Channels0Maximum Number of UART Channels0Maximum Number of USART Channels0Maximum Operating Temperature+85 °CMinimum Operating Temperature-40 °CMounting TypeThrough HoleNumber of ADC Units1Number of PWM Units1Number of Timers3Package TypePDIPPin Count8Program Memory Size2048 x 14 wordsProgram Memory TypeFlashPulse Width Modulation2 x 10 bitPWM Channels2PWM Resolution10bitRAM Size128 BTimer Resolution16 bit, 8 bitTimers1 x 16 bit, 2 x 8 bitTypical Operating Supply Voltage2 → 5.5 VUSB Channels0Width0.28in
