Philips 12 Volts DC 100 mA 7.5 Degree 4 Lead Permanent Magnet Stepper Motor - Phillips
roll over the image to zoom in
£0.00
£31.75
332 947
Phillips
12 Volts DC 100 mA Permanent Magnet Stepper Motor.
A High Quality RS Branded Philips Stepper Motor Designed to work with 12 Volts DC.
7.5º Stepper Motor each with 4 12 Volt Windings (coil) and permanent Magnet Rotor Construction which in turn has braking torque even when not energized.
Designed for unipolar drive, the Motors are easily interfaced to simple and relatively low power electronics, providing a economical means of motion and speed control.
Data Sheet Available below, this is the Size 1 Motor:
Data Sheet 1
Each Stepper Motor Comes with a Booklet Guide and specification sheet.
Shop Categories  NEW RELEASES FEATURED PRODUCTS | Philips 12 Volts DC 100 mA 7.5 Degree 4 Lead Permanent Magnet Stepper Motor
|    |
| Current Rating | 100 mA | |
| Depth | 21.5mm | |
| Holding Torque | 10mNm | |
| Number of Pole Pairs | 2 | |
| Resistance Per Phase | 120Ω | |
| Shaft Diameter | 2mm | |
| Shaft Length | 7.6mm | |
| Step Angle | 7.5° | |
| Stepper Motor Type | Permanent Magnet | |
| Voltage Rating | 12 V dc | |
| Winding Arrangement | Unipolar |
Thank you for looking, if you have any questions please ask or call us.
Please see our other items for a wide range of Electronic components.
