Osram Opto GW KALRB3.EM-TSTU-30H4, SOLERIQ E 45 Series White CoB LED, 3000K, SMD Package
- BMUK Part # :-765-0494
- BrandOSRAM Opto Semiconductors
- Mfr. Part No.GW KALRB3.EM-TSTU-30H4
Product Details
OSRAM SOLERIQ E Series Chip on Board LEDs
The SOLERIQ E series of LEDs, from OSRAM Opto Semiconductors, provide high flux homogenous light from a compact Chip On Board (COB) package even at high application temperatures. With its high flux output only one Soleriq E LED is required in a luminaire, simplifying the coupling of the source to a secondary optic and ultimately simplifying the design of the finished luminaire. Uniform colour is achieved by narrow white grouping corresponding to a range of 4-step MacAdam ellipses, making the Soleriq E LED ideal for applications including, shopping centres, offices, industrial buildings and high-end residential premises.
High efficacy
Excellent colour reproduction with CRI (Colour Rendering Index)> 80 (typically: 85)
Colour consistency within 4-step MacAdam ellipses
Easy to use metal core board
Stable brightness over lifetime
CoB LEDs, OSRAM Opto Semiconductors
Specifications
| LED Colours | White | |
| Package Type | Chip On Board | |
| Mounting Type | Surface Mount | |
| Number of LEDs | 1 | |
| Forward Voltage | 48 V | |
| Number of Pins | 2 | |
| Viewing Angle | 120 ° | |
| Luminous Flux | 4500 lm | |
| Lens Shape | Round | |
| Dimensions | 36.15 x 1.25mm | |
| Series | SOLERIQ E 45 | |
| Colour Temperature | 3000K |
For a Specification PDF Please CLICK HERE
