70W Single Output LED Power Supply HLG-60H-C series

The Mean Well HLG-60H-C LED Power supply is a 70W high efficient LED driver, with high output voltage and low current rating. This LED power supplies are perfect for low to middle wattage LED lighting applications. The HLG-60H-C has a fully potted IP65 structure and enclosed aluminium case giving protection from dust and moisture from outdoor or indoor harsh environments. This LED driver has a constant voltage (C.V.) and constant current (C.C.) design, they have a built in two stage active PFC function and comply with harmonic current limitation per EN61000-3-2 Class C (>60% load). The HLG-60H-C also comply with PF>0.9 if loading over 50% and has a 4KV surge immunity (EN61000-4-5) ability making it suitable for the requirements of street lighting. The HLG-60H-C has an up to date high efficiency topology, with up to 91% high efficiency, it can be cooled by free air convection from -40℃ to +70℃ ambient temperature, meeting the requirements of closed lighting systems. This Power supply is protected for short circuit, over voltage, overload, and over temperature and has a three-in-one dimming function. This LED driver is suitable for applications like LED street lighting, LED tunnel lighting, LED spot lighting, LED decorative lighting, and other indoor/outdoor LED lighting.

Constant current design
Universal AC input / Full range (up to 305VAC)
Built-in active PFC function
High efficiency up to 91%
Protections: Short circuit / Over voltage / Over temperature
Cooling by free air convection
Output current adjustable through output cable or internal potentiometer
IP67 design for indoor or outdoor installations
Three in one dimming function (1∼10Vdc or 10V PWM signal or resistance)
Suitable for dry / damp / wet locations
5 years warranty
