1 x Legris 3310 10 21, 2 x 1/2 in, 6 x 1/2 in out Manifold, Aluminium - Legris
roll over the image to zoom in
£0.00
£82.99
RS 492-8508
Unit Quantity:
1
Unit Type:
Unit
Location:
TS 48M
Legris
Legris 8 stations G 1/2 Manifold, Aluminium 1/2 in G
- BMUK Part # :-492-8508
- BrandLegris
- Mfr. Part No.3310 10 21
-
- You will get 1 Manifold
Product Details
Multiple Outlet Manifolds
| Dimensions (mm) | ||||||
| Part No. | ØD | C2 | Outlets | E | K | N |
| 3310 04 13 | 4 | 1/4" | 8 | 10 | 16.75 | 11.5 |
| 3310 06 13 | 6 | 1/4" | 8 | 10 | 13.5 | 12.5 |
| 3310 06 17 | 8 | 3/8" | 6 | 12 | 19.0 | 15.0 |
| 3310 10 21 | 10 | 1/2" | 6 | 16 | - | 17.1 |
| 3310 12 21 | 12 | 1/2" | 6 | 16 | - | 20.5 |
Bulkhead Adaptors and Manifolds
A range of pneumatic tube bulkhead adaptors and multiple-outlet fittings, all featuring nitrile rubber ’O’ rings for optimum sealing and a working temperature range of -20 to + 80°C.
Specifications
| Manufacturer Series | 3310 | |
| Type | Manifold | |
| Number of Stations | 8 | |
| Connection Port Thread | G 1/2 | |
| Body Material | Aluminium | |
| Thread Size | 1/2 in | |
| Thread Standard | G |
