Fairchild FQA170N06 N-channel MOSFET Transistor 170A 60V 5V Gate TO3PN Arduino - Fairchild Semiconductor

roll over the image to zoom in

£0.00
£8.25
RS 671-4904
Earn0
reward points

In stock: 24

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    3D Draws 89


    Fairchild Semiconductor

     Fairchild FQA170N06 N-channel MOSFET Transistor, 170 A, 60 V, 3-Pin TO-3PN

    You will get ONE MOSFET Transistor in Anti Static packing



    Product Details

    QFET® N-Channel MOSFET, over 31A, Fairchild Semiconductor

    Fairchild Semiconductor’s new QFET® planar MOSFETs use advanced, proprietary technology to offer best-in-class operating performance for a wide range of applications, including power supplies, PFC (Power Factor Correction), DC-DC Converters, Plasma Display Panels (PDP), lighting ballasts, and motion control.
    They offer reduced on-state loss by lowering on-resistance (RDS(on)), and reduced switching loss by lowering gate charge (Qg) and output capacitance (Coss). By using advanced QFET® process technology, Fairchild can offer an improved figure of merit (FOM) over competing planar MOSFET devices.



    MOSFET Transistors, Fairchild Semiconductor

    Fairchild offers a substantial portfolio of MOSFET devices that includes high-voltage (>250V) and low-voltage (<250V). The advanced silicon technology provides smaller die sizes, which it is incorporated into multiple industry-standard and thermally-enhanced packages.
    Fairchild MOSFETs provide superior design reliability from reduced voltage spikes and overshoot, to lower junction capacitance and reverse recovery charge, to elimination of additional external components to keep systems up and running longer.





    CategoryPower MOSFET
    Channel ModeEnhancement
    Channel TypeN
    ConfigurationSingle
    Dimensions15.8 x 5 x 18.9mm
    Height18.9mm
    Length15.8mm
    Maximum Continuous Drain Current        170 A
    Maximum Drain Source Resistance0.006 Ω
    Maximum Drain Source Voltage60 V
    Maximum Gate Source Voltage±25 V
    Maximum Operating Temperature+175 °C
    Maximum Power Dissipation375 W
    Minimum Operating Temperature-55 °C
    Mounting TypeThrough Hole
    Number of Elements per Chip1
    Package TypeTO-3PN
    Pin Count3
    Typical Gate Charge @ Vgs220 nC V @ 10
    Typical Input Capacitance @ Vds7200 pF V @ 25
    Typical Turn-Off Delay Time260 ns
    Typical Turn-On Delay Time85 ns
    Width5mm





    For a Specification PDF Please CLICK HERE
