EPCOS TDK B43415-S9328 3200uF 400V Photo Flash Capacitor High Power PULSE Xenon - Epcos
roll over the image to zoom in
£0.00
£52.95
Epcos B43415-S9328-A3
Unit Quantity:
1
Capacitor Construction:
Aluminium Electrolytic (Polarised)
Epcos
EPCOS TDK B43415-S9328-A3 3200uF 400V Pulse Application Capacitor High Power Photo Flash
You will get 1 Capacitor
The EPCOS B43415 Series is a range of Aluminum electrolytic capacitors designed specifically for pulse applications such as Xenon tube firing in Photo Flash units,
Primary Application
Professional flash light generators
Features
Compact design
Outstanding reliability
High charge/discharge proof, polar
Low leakage current
Low dissipation factor
RoHS-compatible
Construction
Aluminum case, fully insulated
Safety vent
Solder lug Terminals
This capacitor measures 45mm x 105mm and its rated at 3200uF at 400V,
Useful life > 100000 discharges at :-
Case temperature ≤ 60 °C,
∆C/C ≤ ±20% of initial value ,
Discharge repetition rate ≥ 2 s
ESR ≤ 3 times initial specified limit
Max. discharges per week ≤ 5000
Charge resistance > 10 Ω
Discharge resistance > 0.5 Ω
This B43415-S9328-A3 version of the capacitor is a custom version made in September 2015 for Sony to use in a professional photo flash unit, you will see in the data sheet link shown at the end of the description that the closest STANDARD capacitor in the range is 3000uF at 400V and that measures 40mm x 105mm, this custom version is rated at 3200uF and because of the extra capacitance this one is 45mm diameter, Sony also specified that this capacitor was supplied with leads pre soldered to the terminals, these are Red and Black and around 80mm in length from the capacitor terminal to the push on crimp connector, the BLACK wire has a 6.35mm insulated terminal fitted and the RED wire has a 4.8mm insulated terminal,
Primary Application
Professional flash light generators
Features
Compact design
Outstanding reliability
High charge/discharge proof, polar
Low leakage current
Low dissipation factor
RoHS-compatible
Construction
Aluminum case, fully insulated
Safety vent
Solder lug Terminals
This capacitor measures 45mm x 105mm and its rated at 3200uF at 400V,
Useful life > 100000 discharges at :-
Case temperature ≤ 60 °C,
∆C/C ≤ ±20% of initial value ,
Discharge repetition rate ≥ 2 s
ESR ≤ 3 times initial specified limit
Max. discharges per week ≤ 5000
Charge resistance > 10 Ω
Discharge resistance > 0.5 Ω
This B43415-S9328-A3 version of the capacitor is a custom version made in September 2015 for Sony to use in a professional photo flash unit, you will see in the data sheet link shown at the end of the description that the closest STANDARD capacitor in the range is 3000uF at 400V and that measures 40mm x 105mm, this custom version is rated at 3200uF and because of the extra capacitance this one is 45mm diameter, Sony also specified that this capacitor was supplied with leads pre soldered to the terminals, these are Red and Black and around 80mm in length from the capacitor terminal to the push on crimp connector, the BLACK wire has a 6.35mm insulated terminal fitted and the RED wire has a 4.8mm insulated terminal,
