1 x STMicro M27C256B-10C6, OTP EPROM Memory 256kbit 32K x 8bit 100ns, 5V - STMicroelectronics
roll over the image to zoom in
£0.00
£13.99
RS 686-2481
Unit Quantity:
1
Unit Type:
Unit
Location:
BRA 6 O ORANGE
STMicroelectronics
STMicroelectronics M27C256B-10C6, OTP EPROM Memory 256kbit 32K x 8 bit 100ns, 5V PLCC 32-Pin
- BMUK Part # :-686-2481
- BrandSTMicroelectronics
- Mfr. Part No.M27C256B-10C6
-
- You will get 1 Memory
Product Details
EPROM (One Time Programmable), STMicroelectronics
EPROM OTP (One Time Programmable)
These EPROM (Erasable Programmable Read-Only Memory) devices contain the same chips and are programmed in the same way as their UV-eraseable counterparts. However as the package contains no window, they cannot be erased and re-programmed.
Specifications
| Memory Size | 256kbit | |
| Organisation | 32K x 8 bit | |
| Interface Type | Parallel | |
| Maximum Random Access Time | 100ns | |
| Programming Voltage | 12.75V | |
| Reprogramming Technique | OTP | |
| In System Programmability | External | |
| Mounting Type | Surface Mount | |
| Package Type | PLCC | |
| Pin Count | 32 | |
| Dimensions | 14.05 x 11.51 x 2.8mm | |
| Height | 2.8mm | |
| Length | 14.05mm | |
| Maximum Operating Supply Voltage | 5.5 V | |
| Typical Operating Supply Voltage | 5 V | |
| Minimum Operating Supply Voltage | 4.5 V | |
| Width | 11.51mm | |
| Minimum Operating Temperature | -40 °C | |
| Maximum Operating Temperature | +85 °C |
