Batch of TE Connectivity RT425524 DPDT PCB Mount Relay , 24V Coil - TE Connectivity
TE Connectivity
TE Connectivity DPDT PCB Mount Non-Latching Relay, 24V Coil
- BMUK Part # :-680-3903
- BrandTE Connectivity
- Mfr. Part No.RT425524
-
- You will get 1 Batch of Relays

TE Connectivity RT1 and RT2 Series PCB Power Relays
RT Series 1 and Series 2 through hole mounting PCB power relays with a variety of contact configurations and coil voltages.
RT1 PCB power relays are 12A, have 3.5mm pinning and are flux proof
RT2 PCB power relays are 12A, have 5mm pinning and are flux proof
RT3 PCB power relays are 16A, have 5mm pinning and are flux proor
RTB PCB power relays are 12A, have 3.5mm pinning and are wash tight
RTD PCB power relays are 16A, have 5mm pinning and are wash tight
RT4 PCB power relays are 8A, have 5mm pinning and are flux proof
RTE PCB power relays are 8A, have 5mm pinning and are wash tight
Creepage and Clearance 10//10 mm
Applications: interface, automation, domestic applications, security lighting, heating systems
Approvals
UL, CSA, VDE
Coil Voltage | 24 V | |
Contact Configuration | DPDT | |
Mounting Type | PCB Mount | |
Terminal Type | Through Hole | |
Coil Resistance | 350 Ω | |
Application | Power | |
Length | 29mm | |
Depth | 12.7mm | |
Height | 15.7mm | |
Dimensions | 29 x 12.7 x 15.7mm | |
Minimum Operating Temperature | -40°C | |
Contact Material | Gold Plated | |
Operating Temperature Range | -40 → +70°C | |
Maximum Operating Temperature | +70°C | |
Maximum Switching Power AC | 2 kVA |
