740 x Bourns SRN3015-2R2M Shielded Wire-wound SMD Inductor, Ferrite Core, 2.2uH - Bourns

roll over the image to zoom in

£0.00
£148.99
RS 743-5056P
Earn0
reward points

In stock: 1

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    740
    Unit Type:
    Unit
    Location:
    ES-6D


    Bourns

    Bourns SRN3015 Series Type 3015 Shielded Wire-wound SMD Inductor with a Ferrite Core, 2.2 μH ±20% Wire-Wound 1.8A Idc


    • BMUK Part # :-743-5056P
    • BrandBourns
    • Mfr Part No.SRN3015-2R2M
    •  Bourns
    •
    • You will get a Reel of 740 Inductors










    Product Details

    SRN3015 Series Semi Magnetically Shielded Wire Wound Chokes

    Bourns SRN3015 series miniature SMD semi-shielded power inductors feature an inductance range of 1 to 47uH and a rated current up to 2.2A, operating temperature of -40°C to +125°C. These inductors are suitable for the automotive industry and are AEC-Q200 qualified.






    Bourns Non Standard SMT Inductors (Chokes)

    Specifications

    Length
    3mm
    Shielded
    Yes
    Depth
    3mm
    Brand
    Bourns
    Inductor Construction
    Wire-Wound
    Dimensions
    3 x 3 x 1.5mm
    Package/Case
    3015
    Maximum Operating Temperature
    +125°C
    Maximum DC Resistance
    72mΩ
    Maximum dc Current
    1.8A
    Minimum Operating Temperature
    -40°C
    Series
    SRN3015
    Height
    1.5mm
    Core Material
    Ferrite
    Maximum Self Resonant Frequency
    90MHz
    Tolerance
    ±20%
    Inductance
    2.2 μH
