5x Toshiba TPCA8011-H(TE12L,Q) N-channel MOSFET Transistor 40A 20V 8-Pin SOP Adv - Toshiba

roll over the image to zoom in

£0.00
£7.25
RS 415-370
Earn0
reward points

In stock: 299

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    5
    Unit Type:
    Unit
    Location:
    APR BOX E


    Toshiba

    Toshiba TPCA8011-H(TE12L,Q) N-channel MOSFET Transistor, 40 A, 20 V, 8-Pin SOP Advanced



    You get 5 Transistors,
    These c    ome's on SM tape, multi buy's come all in one strip,

    Product Details

    N-Channel MOSFETs 40A to 42A

    MOSFETs - N-Channel

    The Metal–Oxide–Semiconductor Field-Effect Transistor or MOSFET is a transistor used for amplifying or switching electronic signals.
    A voltage on the oxide-insulated Gate electrode can induce a conducting channel between the two other contacts called Source and Drain





    Specifications

    CategoryPower MOSFET
    Channel ModeEnhancement
    Channel TypeN
    ConfigurationQuad Drain, Single, Triple Source
    Dimensions5 x 5 x 0.95mm
    Height0.95mm
    Length5mm
    Maximum Continuous Drain Current 40 A
    Maximum Drain Source Resistance0.004 Ω
    Maximum Drain Source Voltage20 V
    Maximum Gate Source Voltage±12 V
    Maximum Operating Temperature+150 °C
    Maximum Power Dissipation45 W
    Minimum Operating Temperature-55 °C
    Mounting TypeSurface Mount
    Number of Elements per Chip1
    Package TypeSOP Advanced
    Pin Count8
    Typical Gate Charge @ Vgs32 nC V @ 5
    Typical Input Capacitance @ Vds2900 pF V @ 10
    Width5mm



    For a specification PDF Please CLICK HERE

    Thank you for looking, if you have any questions please ask or call us.
