5x International Rectifier IRF5210LPBF P-channel MOSFET Transistor, 38A, 100V - International Rectifier

roll over the image to zoom in

£0.00
£5.99
RS 650-3707
Earn0
reward points

In stock: 12

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    5
    Unit Type:
    Unit
    Location:
    TS 37R


    International Rectifier

    International Rectifier IRF5210LPBF P-channel MOSFET Transistor, 38 A, 100 V, 3-pin TO-262
    • BMUK Part # :-650-3707
    • BrandInternational Rectifier
    • Mfr. Part No.IRF5210LPBF
    International Rectifier

    You will receive 5 Transistors in an Anti Static bag
    International Rectifier IRF5210LPBF P-channel MOSFET Transistor, 38 A, 100 V, 3-pin TO-262
    Image representative of range

      Product Details

      P-Channel Power MOSFET over 8A, International Rectifier

      International Rectifier's range of discrete HEXFET® power MOSFETs includes P-channel devices in surface mount and leaded packages and form factors that can address almost any board layout and thermal design challenge. Across the range benchmark on resistance drives down conduction losses, allowing designers to deliver optimum system efficiency.

      MOSFET Transistors, International Rectifier

      International Rectifier’s comprehensive portfolio of rugged single- and dual- N-channel and P-channel devices offers fast switching speeds and addresses a wide variety of power requirements in applications ranging from AC-DC and DC-DC power supplies to audio and consumer electronics and from motor control to lighting and home appliances.





      CategoryPower MOSFET
      Channel ModeEnhancement
      Channel TypeP
      ConfigurationSingle
      Dimensions10.54 x 4.69 x 10.54mm
      Height10.54mm
      Length10.54mm
      Maximum Continuous Drain Current            38 A
      Maximum Drain Source Resistance0.06 Ω
      Maximum Drain Source Voltage100 V
      Maximum Gate Source Voltage±20 V
      Maximum Operating Temperature+150 °C
      Maximum Power Dissipation3.1 W
      Minimum Operating Temperature-55 °C
      Mounting TypeThrough Hole
      Number of Elements per Chip1
      Package TypeTO-262
      Pin Count3
      Typical Gate Charge @ Vgs150 nC@ 10 V
      Typical Input Capacitance @ Vds2780 pF@ 25 V
      Typical Turn-Off Delay Time72 ns
      Typical Turn-On Delay Time14 ns
      Width4.69mm



      For a Specification PDF Please CLICK HERE
