500 x Nxp 2N7002E,215 N-channel MOSFET Transistor, 380mA, 60V, 3-Pin - Panasonic
roll over the image to zoom in
£0.00
£55.99
RS 725-8307P
Unit Quantity:
500
Unit Type:
Unit
Location:
APR BOX R
Panasonic
NXP 2N7002E,215 N-channel MOSFET Transistor, 380 mA, 60 V, 3-Pin SOT-23
- BMUK Part # :- 725-8307P
- BrandNXP
- Mfr. Part No.2N7002E,215
-
- You will get 500 Transistors on a Reel
Product Details
N-Channel MOSFET, 60V to 80V, Nexperia
MOSFET Transistors, NXP Semiconductors
Specifications
| Channel Type | N | |
| Maximum Continuous Drain Current | 380 mA | |
| Maximum Drain Source Voltage | 60 V | |
| Maximum Drain Source Resistance | 3 Ω | |
| Maximum Gate Threshold Voltage | 2.5V | |
| Minimum Gate Threshold Voltage | 1V | |
| Maximum Gate Source Voltage | -30 V, +30 V | |
| Package Type | TO-236AB | |
| Mounting Type | Surface Mount | |
| Transistor Configuration | Single | |
| Pin Count | 3 | |
| Channel Mode | Enhancement | |
| Category | Power MOSFET | |
| Maximum Power Dissipation | 830 mW | |
| Dimensions | 3 x 1.4 x 1mm | |
| Length | 3mm | |
| Height | 1mm | |
| Width | 1.4mm | |
| Number of Elements per Chip | 1 | |
| Minimum Operating Temperature | -65 °C | |
| Typical Gate Charge @ Vgs | 0.69 nC @ 10 V | |
| Typical Input Capacitance @ Vds | 31 pF @ 10 V | |
| Maximum Operating Temperature | +150 °C |
