50 x Fairchild FDV302P P-channel MOSFET Transistor 0.12A 25V SMD ESD Protection - Fairchild

roll over the image to zoom in

£0.00
£5.99
RS 354-4935
Earn0
reward points

In stock: 397

Sorry! We're out of stock

Add To Your Wishlist


    Fairchild

    Fairchild FDV302P P-channel MOSFET Transistor, 0.12 A, 25 V, 3-Pin SOT-23

    You get 50 MOSFET Transistors, each in a section of SM Tape in an Anti static bag,


    Product Details

    Enhancement Mode P-Channel MOSFET, Fairchild Semiconductor

    Enhancement Mode Field Effect Transistors are produced using Fairchild’s proprietary, high cell density, DMOS technology. This very high density process has been designed to minimize on-state resistance, provide rugged and reliable performance and fast switching.

     .

    https://img-europe.electrocomponents.com/largeimages/L354489-01.gif
    https://img-europe.electrocomponents.com/largeimages/L354490-01.gif








    MOSFET Transistors, Fairchild Semiconductor

    Fairchild offers a substantial portfolio of MOSFET devices that includes high-voltage (>250V) and low-voltage (<250V). The advanced silicon technology provides smaller die sizes, which it is incorporated into multiple industry-standard and thermally-enhanced packages.
    Fairchild MOSFETs provide superior design reliability from reduced voltage spikes and overshoot, to lower junction capacitance and reverse recovery charge, to elimination of additional external components to keep systems up and running longer.

    Specifications

    CategoryPower MOSFET
    Channel ModeEnhancement
    Channel TypeP
    ConfigurationSingle
    Dimensions2.92 x 1.3 x 0.93mm
    Height0.93mm
    Length2.92mm
    Maximum Continuous Drain Current.             0.12 A
    Maximum Drain Source Resistance10 Ω
    Maximum Drain Source Voltage25 V
    Maximum Gate Source Voltage8 V
    Maximum Operating Temperature+150 °C
    Maximum Power Dissipation0.35 W
    Minimum Operating Temperature-55 °C
    Mounting TypeSurface Mount
    Number of Elements per Chip1
    Package TypeSOT-23
    Pin Count3
    Typical Gate Charge @ Vgs0.22 nC @ 4.5 V
    Typical Input Capacitance @ Vds11 pF @ 10 V
    Typical Turn-Off Delay Time9 ns
    Typical Turn-On Delay Time5 ns
    Width1.3mm

    For a Specification PDF Please CLICK HERE
