5 x Wurth Elektronik 100uF Electrolytic Capacitor 25VDC, 860010473007 - Wurth Elektronik

roll over the image to zoom in

£0.00
£4.99
RS 839-6958
Earn0
reward points

In stock: 280

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    5
    Unit Type:
    Unit
    Location:
    TS SHELF


    Wurth Elektronik

    Wurth Elektronik 100μF Electrolytic Capacitor 25V dc, Through Hole - 860010473007


    • BMUK Stock No.839-6958
    • BrandWurth Elektronik
    • Mfr Part No.860010473007
    •
    • You will get FIVE capacitors





    Wurth Elektronik 100μF Electrolytic Capacitor 25V dc, Through Hole - 860010473007



    Product Details

    Wurth Elektronik WCAP-ATG8 Series 85°C, 0.01μF - 1000μF

    WCAP-ATG8 Aluminium Electrolytic Capacitor series

    Features and Benefits

    • Wide Capacitance value range
    • Load life: 2000h @ +85°C
    • Wave soldering recommended
    • Operating temperature: -40°C to +85°C for UR < 400 V
    -25 °C to +85°C for UR ≥ 400 V

    Specifications

    Voltage
    25V dc
    Technology
    Electrolytic
    Mounting Type
    Through Hole
    Brand
    Wurth Elektronik
    Dimensions
    6.3 (Dia.) x 11mm
    Capacitance
    100µF
    Diameter
    6.3mm
    Maximum Operating Temperature
    +85°C
    Minimum Operating Temperature
    -40°C
    Series
    WCAP-ATG8
    Height
    11mm
    Ripple Current
    209mA
    Lead Pitch
    2.5mm
    Leakage Current
    25 μA
    Lifetime
    2000h
    Tolerance
    ±20%
    Dissipation Factor
    14
