5 x Vishay IHLP121BZ-11 Series Shielded Wire-wound SMD Inductor 1.2 uH ±20% 5A - Vishay
roll over the image to zoom in
£0.00
£3.50
RS 748-6694
Unit Quantity:
5
Unit Type:
Unit
Location:
APR SHELF BOX 1
Vishay
Vishay IHLP121BZ-11 Series Shielded Wire-wound SMD Inductor 1.2 μH ±20% 5A IdcYou will get a batch of 5 IHLP1212BZER1R2M11 Inductors on SM Tape, Multi Purchases will all come on one tape,
Product Details
IHLP1212BZ-11 Series Magnetically Shielded Wire Wound Chokes
Vishay IHLP-1212BZ-11 series high current low profile shielded inductors. The IHLP-1212BZ-11 series handles high transient current spikes without saturation and has ultra low buzz noise due to its composite construction.
Frequency range up to 1.0 MHz
Lowest DC Resistance / μH, in this package size
Halogen-free according to IEC 61249-2-21 definition
Applications include: PDA/notebook/desktop/server devices; High current POL converters; Low profile, high current power supplies; Battery powered devices; DC/DC converters in distributed power systems; DC/DC converter for Field Programmable Gate Array (FPGA)
| Depth | 3mm | |
| Dimensions | 3.6 x 3 x 2mm | |
| Height | 2mm | |
| Inductance | 1.2 μH | |
| Length | 3.6mm | |
| Maximum DC Current | 5A | |
| Maximum DC Resistance | 27mΩ | |
| Maximum Operating Temperature | +125°C | |
| Maximum Self Resonant Frequency. | 1MHz | |
| Minimum Operating Temperature | -55°C | |
| Package/Case | 1212 | |
| Series | IHLP121BZ-11 | |
| Shielded | Yes | |
| Tolerance | ±20% |
Specification PDF Please CLICK HERE
Thank you for looking, if you have any questions please ask or call us.
Please see our other items for a wide range of Electronic components.
