5 x Vishay IHLP121BZ-11 Series Shielded Wire-wound SMD Inductor 0.47 uH ±20% 6A - Vishay
roll over the image to zoom in
£0.00
£6.99
RS 748-6754
Unit Quantity:
5
Maximum DC Current:
6A
Inductance:
0.47uh
Location:
APR SHELF BOX 2
Vishay
Vishay IHLP121BZ-11 Series Shielded Wire-wound SMD Inductor 0.47 μH ±20% 6A IdcYou will get a batch of 5 IHLP1616ABERR47M11 Inductors on SM Tape, Multi Purchases will all come on one tape,
Product Details
IHLP1616AB-11 Series Magnetically Shielded Wire Wound Chokes
Vishay IHLP-1616AB-11 series high current low profile shielded inductors. The IHLP-1616AB-11 series handles high transient current spikes without saturation and has ultra low buzz noise due to its composite construction.
Frequency range up to 1.0 MHz
Lowest DC Resistance / μH, in this package size
Applications include: PDA/notebook/desktop/server devices; High current POL converters; Low profile, high current power supplies; Battery powered devices; DC/DC converters in distributed power systems; DC/DC converter for Field Programmable Gate Array (FPGA)
Vishay Non Standard SMT Inductors (Chokes)
| Depth | 4.06mm | |
| Dimensions | 4.45 x 4.06 x 1.2mm | |
| Height | 1.2mm | |
| Inductance | 0.47 μH | |
| Length | 4.45mm | |
| Maximum DC Current | 6A | |
| Maximum DC Resistance | 21mΩ | |
| Maximum Operating Temperature | +125°C | |
| Maximum Self Resonant Frequency. | 1MHz | |
| Minimum Operating Temperature | -55°C | |
| Package/Case | 1616 | |
| Series | IHLP121BZ-11 | |
| Shielded | Yes | |
| Tolerance | ±20% |
Specification PDF Please CLICK HERE
