5 x Vishay 1000V 3A, Diode, 2-Pin DO-201AD 1N5408-E3/54 - Vishay

roll over the image to zoom in

£0.00
£5.49
RS 628-9502
Earn0
reward points

In stock: 14

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    5
    Unit Type:
    Unit
    Location:
    ES-11D


    Vishay

    Vishay 1000V 3A, Diode, 2-Pin DO-201AD 1N5408-E3/54

    • BMUK Stock No.628-9502
    • BrandVishay
    • Mfr Part No.1N5408-E3/54
    •
    •  Vishay
    •
    • You will get FIVE diodes
    Vishay 1000V 3A, Diode, 2-Pin DO-201AD 1N5408-E3/54
    Product Details

    Vishay 1N5400-1N5408 General Purpose Plastic Rectifiers

    From Vishay, 1N5400-1N5408 are a range of general purpose rectifiers. With a moulded epoxy body, this range of rectifiers have a DO-201AD package size.

    Diodes and Rectifiers, Vishay Semiconductor

    Specifications
    Diode Configuration
    Single
    Maximum Operating Temperature
    +150 °C
    Number of Elements per Chip
    1
    Length
    9.5mm
    Brand
    Vishay
    Package Type
    DO-201AD
    Maximum Continuous Forward Current
    3A
    Mounting Type
    Through Hole
    Minimum Operating Temperature
    -50 °C
    Width
    5.3mm
    Diameter
    5.3mm
    Height
    5.3mm
    Maximum Forward Voltage Drop
    1.2V
    Pin Count
    2
    Dimensions
    5.3 x 9.5 x 5.3mm
    Peak Non-Repetitive Forward Surge Current
    200A
    Peak Reverse Current
    5µA
    Peak Reverse Repetitive Voltage
    1000V
    Diode Technology
    Silicon Junction
