5 x Texas Instruments TL072CD, Dual Op Amp, Surface Mount, 3MHz, 8-Pin - Texas Instruments
roll over the image to zoom in
£0.00
£7.49
RS 857-907P
Unit Quantity:
10
Unit Type:
Unit
Location:
TS BRA-1A
Texas Instruments
Texas Instruments TL072CD, Dual Op Amp, 3MHz, 8-Pin SOIC
- BMUK Part # :-857-907P
- BrandTexas Instruments
- Mfr. Part No.TL072CD
- You will get a pack of 5 Op Amps
Product Details
JFET Input Op Amp, TL070 & TL080 Families
A range of well-established high-performance JFET input, bipolar output operational amplifiers from Texas Instruments featuring low input bias currents and high slew rates. These op amps have low noise and low distortion and are suitable for a wide variety of audio and signal processing applications. The high input impedance makes them an ideal choice where circuit loading must be minimized. Offset adjustment and external compensation options are available with the single TL071 and TL081 devices.
• Low input bias and offset currents
• Wide supply voltage range: ±5 to ±15V
• Low noise: 18nV/√Hz typical at 1 kHz
• High Slew Rate: 13 V/μs typical
• Low Total Harmonic Distortion: 0.003% typical
• Single, Dual and Quad devices available
Operational Amplifiers, Texas Instruments
Specifications
| Mounting Type | Surface Mount | |
| Package Type | SOIC | |
| Power Supply Type | Dual | |
| Number of Channels per Chip | 2 | |
| Pin Count | 8 | |
| Typical Gain Bandwidth Product | 3MHz | |
| Typical Dual Supply Voltage | ±12 V, ±15 V, ±5 V, ±9 V | |
| Typical Slew Rate | 13V/µs | |
| Minimum Operating Temperature | 0 °C | |
| Maximum Operating Temperature | +70 °C | |
| Typical Voltage Gain | 106.02 dB | |
| Width | 3.91mm | |
| Height | 1.58mm | |
| Length | 4.9mm | |
| Typical Input Voltage Noise Density | 18nV/√Hz | |
| Dimensions | 4.9 x 3.91 x 1.58mm |
