5 x STMicroelectronics STP2N62K3 N-channel MOSFET Transistor, 2.2A, 620V, 3-Pin - STMicroelectronics
roll over the image to zoom in
£0.00
£14.99
RS 760-9682
Unit Quantity:
5
Unit Type:
Unit
Location:
ES-5K
STMicroelectronics
STMicroelectronics STP2N62K3 N-channel MOSFET Transistor, 2.2 A, 620 V MDmesh K3, SuperMESH3, 3-Pin TO-220
- BMUK Part # :-760-9682
- BrandSTMicroelectronics
- Mfr Part No.STP2N62K3
- You will get a pack of 5 Transistors
Product Details
N-channel MDmesh™ K3 series, SuperMESH3™, STMicroelectronics
MOSFET Transistors, STMicroelectronics
Specifications
Maximum Operating Temperature
+150 °C
Number of Elements per Chip
1
Length
10.4mm
Typical Turn-On Delay Time
8 ns
Brand
STMicroelectronics
Typical Turn-Off Delay Time
21 ns
Maximum Continuous Drain Current
2.2 A
Package Type
TO-220
Maximum Power Dissipation
45 W
Series
MDmesh K3, SuperMESH3
Mounting Type
Through Hole
Width
4.6mm
Maximum Gate Threshold Voltage
4.5V
Height
15.75mm
Minimum Gate Threshold Voltage
3V
Maximum Drain Source Resistance
3.6 Ω
Maximum Drain Source Voltage
620 V
Pin Count
3
Dimensions
10.4 x 4.6 x 15.75mm
Category
Power MOSFET
Typical Gate Charge @ Vgs
15 nC @ 10 V
Channel Mode
Enhancement
Typical Input Capacitance @ Vds
340 pF @ 50 V
Channel Type
N
Maximum Gate Source Voltage
-30 V, +30 V
