5 x STMicro STL40DN3LLH5 Dual N-channel MOSFET Transistor 40A 30V 8-Pin - STMicroelectronics
roll over the image to zoom in
£0.00
£7.99
RS 761-0578
Unit Quantity:
5
Unit Type:
Unit
Location:
ES-4J
STMicroelectronics
STMicroelectronics STL40DN3LLH5 Dual N-channel MOSFET Transistor, 40 A, 30 V STripFET, 8-Pin PowerFLAT
- BMUK Part # :-761-0578
- BrandSTMicroelectronics
- Mfr Part No.STL40DN3LLH5
- You will get a pack of 5 Transistors
Product Details
N-Channel STripFET™ Dual MOSFET, STMicroelectronics
STripFET™ MOSFETs with a wide breakdown voltage range offer ultra-low gate charge and low on-resistance.
MOSFET Transistors, STMicroelectronics
Specifications
Maximum Operating Temperature
+150 °C
Number of Elements per Chip
2
Length
4.75mm
Typical Turn-On Delay Time
4 ns
Brand
STMicroelectronics
Typical Turn-Off Delay Time
13 ns
Maximum Continuous Drain Current
40 A
Package Type
PowerFLAT
Maximum Power Dissipation
60 W
Series
STripFET
Mounting Type
Surface Mount
Minimum Operating Temperature
-55 °C
Width
5.75mm
Height
0.85mm
Maximum Drain Source Resistance
25 mΩ
Maximum Drain Source Voltage
30 V
Pin Count
8
Dimensions
4.75 x 5.75 x 0.85mm
Category
Power MOSFET
Typical Gate Charge @ Vgs
4.5 nC @ 4.5 V
Channel Mode
Enhancement
Typical Input Capacitance @ Vds
475 pF @ 25 V
Channel Type
N
Maximum Gate Source Voltage
-22 V, +22 V
