    Sharp PC847X7 80V 4 Channel Photocoupler Optocoupler PDIP-16

    You will get 5 x photocouplers

    Description:
    PC847X Series contains an IRED optically coupled to a phototransistor. It is packaged in a 4-channel package, available in SMT gullwing lead-form option. Input-output isolation voltage(rms) is 5.0kV. Collector-emitter voltage is 80V and CTR is 50% to 600% at input current of 5mA.

    Features:
    1. 16pin DIP 4-channnel package
    2. Double transfer mold package (ldeal for Flow Soldering)
    3. High collector-emitter voltage (VCEO : 80V(*))
    4. Current transfer ratio (CTR : MIN. 50% at IF=5mA, VCE=5V)
    5. Several CTR ranks available
    6. High isolation voltage between input and output (Viso(rms) : 5.0kV)

    Applications:
    1. I/O isolation for MCUs (Micro Controller Units)
    2. Noise suppression in switching circuits
    3. Signal transmission between circuits of different potentials and impedances
