5 x RS Pro 630mA Radial Non-Resettable Wire Ended Fuse 250V - RS Pro

roll over the image to zoom in

£0.00
£4.99
RS 767-5109
Earn0
reward points

In stock: 41

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    5
    Unit Type:
    Unit
    Current Rating:
    630mA
    Location:
    D-Off


    RS Pro

    RS Pro 630mA Radial Non-Resettable Wire Ended Fuse, 250 V

          • You will receive a pack of 5 Fuses
          •
                  • BMUK Part # :-767-5109
                  • BrandRS Pro
                  RS Pro
                  RS Pro 125mA Radial Non-Resettable Wire Ended Fuse, 250 V
                  Image representative of range
                  Product Details

                  RS Slow Blow TE5 Fuses

                  RS slow blow TE5 fuses are a convenient and reliable solution to a vast array of application requirements.

                  Base and cap in black thermoplastic, UL 94-V0
                  Round pins in tin-plated copper
                  Vibration MIL-STD-202G, Method 201 (10-55Hz x 3 axis / no load)
                  Salt spray MIL-STD-202G, Method 101, Test Condition B (48 hours)
                  Insulation resistance MIL-STD-202G, Method 302, Test Condition A (After Opening) 10,000 ohms minimum
                  Resistance to solder heat MIL-STD-202G, Material 210, Test Condition B (10 sec @ 260°C)
                  Thermal shock MIL-STD-202G, Method 107, Test Condition B (-65°C to +125°C)

                  PCB Wire Ended - Subminiature

                  PCB Wire Ended

                  All fuses have Thermoplaste Polyamide bodies

                  Specifications
                  Current Rating630mA
                  Lead OrientationRadial
                  Voltage Rating250 V
                  Body MaterialThermoplastic
                  Body Length8.35mm
                  Body Width4.3mm
                  Body Height7.7mm
                  Wire Length4.3 mm, 22 mm
                  Wire Pitch5.08mm
                  Breaking Capacity at Maximum Voltage Rating35 A @ 250 V ac
                  Minimum Operating Temperature-55°C
                  Maximum Operating Temperature+125°C
                  Wire Diameter0.62mm
