5 x Phoenix Contact Feed Through Terminal Block, PT Series , 0.14-1.5mm², 500V - Phoenix contact
roll over the image to zoom in
£0.00
£18.99
RS 750-8514
Type:
Terminal
Unit Quantity:
5
Unit Type:
Unit
Location:
TS-LB 4H
Phoenix contact
Phoenix Contact Feed Through Terminal Block, PT Series , 0.14 → 1.5mm², 500 V, 17.5A, Plug In Termination, Grey
- BMUK Part # :-750-8514
- BrandPhoenix Contact
- Mfr. Part No.PT 1,5/S-QUATTRO/2P - 3212390
-
- You will get a pack of 5 Connectors
Product Details
Feed-Through and Multi-Conductor Terminal Blocks
50 % less insertion force
Direct plugging from 0.34 mm
Actuation button for disconnecting conductors or wiring small cross sections from 0.14 mm
Actuation button can be operated with any kind of screwdriver
Compact design and front connection facilitate wiring in the smallest of spaces
Double bridge shaft for an individual power distribution and supply
Uniform CLIPLINE complete standard accessory
Push-In Connection Terminal Blocks
The PT series is characterised by easy, direct conductor connection, and it consistently uses the advantages of the CLIPLINE complete system. The up to 50% lower insertion forces of the PT push-in connection method also allows easy and direct plugging of solid and stranded conductors with ferrules of 0.34mm2 and up.
Specifications
| Series | PT | |
| Wire Size | 26 → 14 AWG | |
| Cable CSA | 0.14 → 1.5mm² | |
| Colour | Grey | |
| Current Rating | 17.5A | |
| Number of Levels | Single | |
| Termination Method | Plug In | |
| Voltage Rating | 500 V |
