5 x Panasonic ETQPM5 Wire-wound SMD Inductor Metal Composite Core 2.45 uH 14A - Panasonic
roll over the image to zoom in
£0.00
£8.50
RS 570-326
Unit Quantity:
5
Unit Type:
Unit
Location:
APR SHELF BOX 2 AND ANOTHER
Panasonic
Panasonic ETQPM5 Series Wire-wound SMD Inductor with a Metal Composite Core, 2.45 μH ±20% 14A IdcYou will get a batch of 5 ETQP5M2R5YFK Inductors on SM Tape, Multi Purchases will all come on one tape,
Product Details
ETQP5M Series Magnetically Shielded Wire Wound Chokes
High heat resistance
Excellent DC bias characteristics
Low buzz noise
High reliability at high temperatures
High efficiency
Applications
Noise filter for various drive circuitry requiring high temperature operation and large peak current handling capabilityDC-DC converters
| Dimensions (mm) | ||
| Part No. | Type | L x W x H |
| PCC-M0754M (MC) | ETQP5M470YFM | 7.5 x 7 x 5.4 mm |
| PCC-M0854M-220Y | ETQP5M220YFK | 8.5 x 8 x 5.4 mm |
| PCC-M0854M (MC) | ETQP5M2R5YFK | 8.5 x 8 x 5.4 mm |
| PCC-M1054M (MC) | ETQP5M2R5YFC | 10.7 x 10 x 5.4 mm |
Panasonic Non Standard SMT Inductors (Chokes)
| Core Material | Metal Composite | |
| Depth | 8mm | |
| Dimensions | 8.5 x 8 x 5.4mm | |
| Height | 5.4mm | |
| Inductance | 2.45 μH | |
| Length | 8.5mm | |
| Maximum DC Current | 14A | |
| Maximum DC Resistance | 7.6mΩ | |
| Series | ETQPM5 | |
| Tolerance | ±20% |
Specification PDF Please CLICK HERE
