5 x Panasonic ECA2AM220 22uF 100V DC Capacitor 6.3 (Dia.) x 11.2mm 2.5mm Pitch - Panasonic
roll over the image to zoom in
£0.00
£5.95
RS 228-7085
Unit Quantity:
5
Unit Type:
Unit
Capacitor Construction:
Aluminium Electrolytic (Polarised)
Location:
ES-10H
Panasonic
Panasonic 22μF 100V dc Aluminium Electrolytic Capacitor, Through Hole 6.3 (Dia.) x 11.2mm +85°C 6.3mm 2.5mm
- BMUK Stock No.228-7085
- Brand
- Mfr Part No.ECA2AM220
- You Will Get 50 Capacitors
Product Details
M Series
Panasonic M Series Type A electrolytic capacitors feature excellent endurance of 2000 hours at +85°C.
Smaller than SU series
High reliability
High ripple current
Low impedance
Long life
Fully sleeved
Applications
Panasonic M Series Type A electrolytic capacitors are suitable for use in general purpose applications and in industrial instruments due to their high reliability.
| Capacitance Tolerance (%) | 20 |
| Operating Temperature (°C) | -25 to +85 |
| Leakage Current | 0.01CV or 3μA (whichever is the greater) |
| Life expectancy (hours @ 85°C) | 2000 |
Specifications
Voltage
100V dc
Technology
Electrolytic
Mounting Type
Through Hole
Brand
Panasonic
Dimensions
6.3 (Dia.) x 11.2mm
Capacitance
22µF
Diameter
6.3mm
Maximum Operating Temperature
+85°C
Minimum Operating Temperature
-40°C
Series
M
Height
11.2mm
Ripple Current
115mA
Lead Pitch
2.5mm
Leakage Current
3 μA
Lifetime
2000h
Tolerance
±20%
