5 x Panasonic Aluminium Electrolytic Capacitor 15uF 450V dc 12.5mm Through Hole - Panasonic
roll over the image to zoom in
£0.00
£7.49
RS 699-7578
Unit Quantity:
5
Unit Type:
Unit
Location:
TS 8R
Panasonic
Panasonic Aluminium Electrolytic Capacitor 15μF 450 V dc 12.5mm Through Hole series EE RADIAL lifetime 10000h
- BMUK Part # :-699-7578
- BrandPanasonic
- Mfr. Part No.EEUEE2W150
-
- You will get a pack of 5 Capacitors
 |
Product Details
EE Series
Panasonic EE Series Type A electrolytic capacitors feature endurance between 8000 and 10000 hours(dependent on case size). These radial capacitors offer 40% higher ripple current at high frequency than the Panasonic ED series.
High ripple current
Excellent endurance
Low impedance
Applications
Panasonic EE Series Type A electrolytic capacitors are suitable for use in industrial instruments due to their high reliability.
Radial 105°C
Specifications
| Capacitance | 15 µF | |
| Technology | Electrolytic | |
| Voltage | 450 V dc | |
| Dimensions | 12.5 (Dia.) x 25mm | |
| Height | 25mm | |
| Diameter | 12.5mm | |
| Minimum Operating Temperature | -25°C | |
| Maximum Operating Temperature | +105°C | |
| Lead Pitch | 5mm | |
| Construction | Radial | |
| Series | EE RADIAL | |
| Lifetime | 10000h | |
| Tolerance | ±20% | |
| Tolerance Plus | +20% | |
| Ripple Current | 780mA | |
| Terminal Type | Through Hole | |
| Lead Diameter | 0.6mm | |
| Tolerance Minus | -20% |
