5 x Osram Opto SFH 300 FA-3/4 50 ° IR Phototransistor Through Hole 2-Pin Arduino - OSRAM Opto Semiconductors
roll over the image to zoom in
£0.00
£5.99
RS 654-8047
Unit Quantity:
5
Unit Type:
Unit
Location:
TS 9A
OSRAM Opto Semiconductors
Osram Opto SFH 300 FA-3/4 50 ° IR Phototransistor, Through Hole 2-Pin 5mm (T-1 3/4) package
- BMUK Part # :-654-8047
- BrandOSRAM Opto Semiconductors
- Mfr. Part No.SFH 300 FA-3/4
-
- You will get a pack of 5 Phototransistors
 |
Product Details
Phototransistor T-1 3/4 (5mm) Package
This family of NPN silicon phototransistors, from OSRAM Opto Semiconductors, are a range of 5mm (T-1 3/4) through-hole devices. They have both clear or black plastic lenses, the diffused lenses being used for daylight filters. Suitable applications include; computer-controlled flashes, photointerrupters, industrial electronics and for control/drive circuits.
5mm (T-1 3/4) packages
Through-hole mounting
IR Phototransistors, OSRAM Opto Semiconductors
Specifications
| Spectrums Detected | Infrared | |
| Typical Fall Time | 10µs | |
| Typical Rise Time | 10µs | |
| Number of Channels | 1 | |
| Maximum Light Current | 7700µA | |
| Maximum Dark Current | 50nA | |
| Angle of Half Sensitivity | 50 ° | |
| Polarity | NPN | |
| Number of Pins | 2 | |
| Mounting Type | Through Hole | |
| Package Type | 5mm (T-1 3/4) | |
| Dimensions | 5.9 x 5.9 x 9mm | |
| Collector Current | 50mA | |
| Width | 5.9mm | |
| Minimum Wavelength Detected | 730nm | |
| Maximum Wavelength Detected | 1120nm | |
| Height | 9mm | |
| Length | 5.9mm | |
| Spectral Range of Sensitivity | 730 → 1120 nm |
