5 x Osram Opto SFH 2701 IR + Visible Light Photodiode, 60 °, Surface Mount - OSRAM Opto Semiconductors
roll over the image to zoom in
£0.00
£5.99
RS 913-3285
Unit Quantity:
5
Unit Type:
Unit
Location:
APR BOX S
OSRAM Opto Semiconductors
Osram Opto SFH 2701 IR + Visible Light Photodiode, 60 °, Surface Mount Chip LED
- BMUK Part # :-913-3285
- BrandOSRAM Opto Semiconductors
- Mfr. Part No.SFH 2701
-
- You will get a pack of 5 Photodiodes
Product Details
PIN Photodiodes Chipled Package
The SFH 2701, from OSRAM Opto Semiconductors, is a high speed PIN photodiode. It comes in a compact Chipled package with the standard 3216 footprint. The SFH 2701 is a fast PIN photodiode. Suitable applications for the SFH 2701 include; optical disk drives, photointerrupters, industrial electronics and control/drive circuits.
Features of the SFH 2701 photodiode:
3216 ChipLED package
400 to 1050 nm applications
Fast switching tmie
Short decay time
Operating temperature: -40 to +85 °C
Photodiodes, OSRAM Opto Semiconductors
Specifications
| Spectrums Detected | Infrared, Visible Light | |
| Wavelength of Peak Sensitivity | 820nm | |
| Package Type | Chip LED | |
| Mounting Type | Surface Mount | |
| Number of Pins | 2 | |
| Minimum Wavelength Detected | 400nm | |
| Maximum Wavelength Detected | 1050nm | |
| Length | 3.35mm | |
| Width | 1.65mm | |
| Height | 1.25mm | |
| Angle of Half Sensitivity | 60 ° | |
| Peak Photo Sensitivity | 0.5A/W | |
| Polarity | Forward |
