5 x ON Semiconductor MC14069UBCPG, Hex Inverter, 3-18V, 14-Pin - ON Semiconductor
roll over the image to zoom in
£0.00
£5.99
RS 518-9085
Unit Quantity:
10
Unit Type:
Unit
Location:
BRA 8D
ON Semiconductor
ON Semiconductor MC14069UBCPG, Hex Inverter, 3 → 18 V, 14-Pin PDIP
- BMUK Part # :-518-9085
- BrandON Semiconductor
- Mfr. Part No.MC14069UBCPG
-
- You will get a pack of 5 ICs
Product Details
4000 Series Inverters & Buffers, ON Semiconductor
4000 CMOS Logic Family, ON Semiconductor
CMOS Family devices
Wide operating voltage range: 3 to 18V
Specifications
| Logic Function | Inverter | |
| Number of Elements per Chip | 6 | |
| Schmitt Trigger Input | No | |
| Maximum Propagation Delay Time @ Maximum CL | 55 ns @ 15 V, 75 ns @ 10 V, 125 ns @ 5 V | |
| Maximum High Level Output Current | -4.2mA | |
| Maximum Low Level Output Current | 4.2mA | |
| Mounting Type | Through Hole | |
| Package Type | PDIP | |
| Pin Count | 14 | |
| Logic Family | 4000 | |
| Dimensions | 19.56 x 6.6 x 3.68mm | |
| Height | 3.68mm | |
| Propagation Delay Test Condition | 50pF | |
| Maximum Operating Temperature | +125 °C | |
| Minimum Operating Temperature | -55 °C | |
| Maximum Operating Supply Voltage | 18 V | |
| Minimum Operating Supply Voltage | 3 V | |
| Width | 6.6mm | |
| Length | 19.56mm |
